Interior Polished stainless steel/Anodized and exterior finshed in durable Powder coated paints. Control by wet and dry bulb microcontroller/Direct Rh Controller with dual display. Circuit incorporated with solid state relays. Adjustable time delay relay for safety of compressor

APPLICATION : Humidity ovens confirming to standard specification, specifically designed for climatic and durability tests where the Rh value is above freezing point. They are used for drying environment of plant, animal growth ,investigation of vapor proofness of packed material ,determination of die electric strength ,insulation test of electronic component , mechanical assemblies ,paints etc

Model FSC 03,FSC 06, FSC 08 , FSC 10, FSC 12, FSC 15 ,FSC 18,FSC 20,FSC 22 ,FSC 30 CONSTRUCTION : WORKING VOLUME :3,6,8,10,12,15,18,20,22,30 Cu ft. OR As Per Order. INTERIOR : Polished Stainless Steel /Anodized Aluminum. EXTERIOR : Heavy Gauge – mild Steel./ Stainless Steel CAHMBER : Tripled Walled. MOBILITY : On caster wheel. INSULATION : Superior Thermo fiber board/PUF insulation.INNER DOOR : Full view glass with metal frame. OUTER DOOR : Of massive construction having seal against atmospheric infiltration by rubber gasket. SHELVE: Fabricated precisely to give minimum resistance to air circulation. FINISH :Durable Powder coated paint / Stainless steel finish. DESCRIPTION CIRCULATION : Forced air circulation for uniform temp by suction blower with fan. FRONT PANEL: Mains rocker switch, cooling/heating rocker switch ,Microcontroller. Toggle switches for high and low position of heaters, Fuses .ILLUMINATION : With the opening of the door.

TEMPRATURE RANGE : 5 Deg to 50 Deg C , ACCURACY : + 1 Deg C or Better.

CONTROLLER : Micro controller for wet and dry both with dual display.

SENSOR : PT 100 , DISPLAY : Digital LED

HUMIDITY METHOD : Steam injection ,Humidity derived by dry and wet bulb principle.

RANGE :40% to 95%Rh + 5% and better Rh.

DATA LOGGING PORT : Data(TEMP/ humidity/TIME) can be recorded and collected on PEN Drive/Printer/To Computer

HEATING HEATERS : Tubular finned type heaters for dry and wet both.

REFRIGERATION COMPRESSOR : Hermetically sealed , fan cooled condenser. POWER SUPPLY : 230 Volts 50 Hz.AC

Interior Polished stainless steel/Anodized and exterior finshed in durable Powder coated paints. Control by wet and dry bulb microcontroller/Direct Rh Controller with dual display. Circuit incorporated with solid state relays. Adjustable time delay relay for safety of compressor

APPLICATION : Humidity ovens confirming to standard specification, specifically designed for climatic and durability tests where the Rh value is above freesing point. They are used for drying environment of plant, animal growth ,investigation of vapour proofness of packed material ,determination of die electric strength,insulation test of electronic component , mechanical assemblies,paints etc

CONSTRUCTION :

WORKING VOLUME : 3,6,10,12,15,18,20,22,30 Cu ft.

INTERIOR : Polished Stainless Steel /Anodized Aluminum.

EXTERIOR : Heavy Gauge – mild Steel./ Stainless Steel

CAHMBER : Tripled Walled.

MOBILITY : On caster wheel.

INSULATION : Superior Thermo fiber board/PUF insulation.

INNER DOOR : Full view glass with metal frame.

OUTER DOOR : Of massive construction having seal against atmospheric infiltration by rubber gasket.

SHELVES : Fabricated precisely to give minimum resistance to air circulation.

FINISH : Durable Powder coated paint / Stainless steel finish

DESCRIPTION

CIRCULATION : Forced air circulation for uniform temp by suction blower with fan.

FRONT PANEL: Mains rocker switch, cooling/heating rocker switch ,Microcontroller.Toggle switches for high and low position of heaters, Fuses .

ILLUMINATION : With the opening of the door.

TEMPRATURE

RANGE : 5 Deg to 50 Deg C

ACCURACY : + 1 Deg C or Better.

CONTROLLER : Micro controller for wet and dry both with dual display.

SENSOR : PT 100

DISPLAY : Digital LED

HUMIDITY METHOD : Steam injection ,Humidity derived by dry and wet bulb principle.

RANGE : 40% to 95%Rh + 5% and better Rh.

HEATING HEATERS :Tubular finned type heaters for dry and wet both.

REFRIGERATION COMPRESSOR : Hermetically sealed , fan cooled condenser.

POWER SUPPLY : 230 Volts 50 Hz.AC
